HOME 제품소개 Optical Attenuators





  - Telecommunication networks
- CATV system
- Local Area Network
- Instrument


- High power endurance
- Modal Noise suppression
- Compact size, Light weight
- Wavelength Insensitive
- Various connector type available BR>


 Characteristics  Conditions

Value

Min Typ Max
 Attenuation(dB)     1~20
 Return Loss(dB)  SPC  40
   UPC  50
   APC  60
 Attenuation Accuracy  1~10dB     ±1.0
   10~20dB     ±1.5
 Operating Wavelength(nm)  1310 and 1550
 Operating Temperature(°C)  -40~80
 Humidity  75°C, RH 95%

 Attenuation  1~20dB
 Polishing  SPC, UPC, APC
 Connector  SC, FC, LC, MU, ST
 Usage  SM, MM
 Fiber Optic Attenuator In - line type
