[CWDM | DWDM | OADM | WDM] 2. DWDM
100G,200G Optical Add-Drop Multiplexer (1X2) |
|---|
 | | | - Channel Add/Drop - DWDM Network - Wavelength Routing - Fiber Optical Amplifier - CATV fiber optic System |
|  | | | - Low insertion loss - Wide pass band - High channel isolation - High stability and reliability - Epoxy free on optical path |
|
| | | | Parameter | | MUX/DEMUX | | Operating Wavelength (nm) | | ITU Grid | | Center Wavelength Accuracy (nm) | | ±0.05 | ±0.1 | | Channel Spacing (GHz) | | 100 | 200 | | Channel Passband (@-0.5dB bandwidth) (nm) | | >0.22 | >0.5 | | Pass Channel Insertion Loss (dB) | | ≤1.0 | ≤0.9 | | Reflection Channel lnsertion Loss (dB) | | ≤0.6 | ≤0.6 | | Channel Ripple (dB) | | < 0.3 | | Isolation (dB) | Adjacent | >30 | | Non-adjacent | >40 | | lnsertion Loss Temperature Sensitivity (dB/℃) | | >13 | | Express Channel Isolation (dB) | | <0.005 | | Wavelength Temperature Shifting (nm/℃) | | <0.002 | | Polarization Dependent Loss (dB) | | <0.1 | | Polarization Mode Dispersion (ps) | | <0.1 | | Directivity (dB ) | | >50 | | Return Loss (dB) | | >45 | | Maximum Power Handling (mW) | | 500 | | Operating Temperature (°C) | | -10 ~+75 | | Storage Temperature (°C) | | -40 ~+85 | | Package Dimension (mm) | | 5.5 x L34 (L38 for 900um loose tube) |
* Specifications may change without notice. * Above specification are for device without connector. | | **Package Dimension : |  |
|---|
|  |
|
|
|---|
|
|---|
| | a | DWDM Type | F : Filter, A : AWG | b | Channel | 8 : 8Ch, 16 : 16Ch, 32 : 32Ch | c | Channel Space | 50 : 50GHz, 100 : 100GHz, 200 : 200GHz | d | ITU-T Grid | C : C Band, L : L Band, CB : Blue, CR : Red | e | Start ITU-T Wavelength | ITU-T Wavelength | f | Stop ITU-T wavelength | ITU-T Wavelength | g | Fiber Type | 025 : 0.25mm, 09 : 0.90mm, Customized | h | Fiber Length(m) | 1 : 1m, others | i | Connector Type | SC, LC, FC, Customized | j | Ferrule Type | PC, APC | | Dence Wavelength Division Multiplex |
|
|---|
|
